QC-LXG
● Multi-core direct-connection integrated drive and control
● 3 ~ 4 axis servo control
The Huacheng Industrial Control has launched an integrated drive and control product mainly developed for cost - effective application scenarios. It includes two models, QC - L3G and QC - L4G. In response to the environment of CNC machine tool processing and production, oil - resistant cables are used, and the hand controller features a brand - new appearance structure.
Additionally, for the complex loading and unloading scenarios, it has a dual - material tray mode and an independent lathe safety zone is set. It supports collision detection, which can effectively avoid personal and property losses.
Parameter
| Type | Parameter |
| Input voltag | AC200V~240V,50Hz/60Hz |
| Motor power | 100-750W |
| Number of controllable axes | 1-4Axes |
| Levels of protection | Hand controller IP65 / Drive and control unit IP20 Electromotor IP65 |
| Operating temperature and humidity | Temperature:0~40℃(without freezing),Humidity:≤90%RH |
| RS485 | It supports Modbus and allows for IO expansion. |
| IO | 40 channels of input and output |
| Size | Hand controller: 216.7*283.8*(58+43.90)mm Drive and control unit : 304*197*114.3mm |
| Way of installation | Equipment cabinet |
| Heat dissipation method | Built-in Fan |
*All of the above data are obtained in a standard test environment and actual performance may vary.
